Advanced technology.

 株式会社カタ技術は、ワイヤーカット加工、型彫放電加工、レーザカット加工、細穴放電加工の生産技術を通じてMade in Japanのものづくりを支えています。

 KATA GIJUTU Co.,Ltd. supports manufacturing in Japan through production technologies such as Wire Electrical-discharge machining, Electrical-discharge machining, Light Amplification by Stimulated Emission of Radiation, and Electrical-discharge machining Drill.

ワイヤー加工 放電加工 レーザ加工 細穴加工 求人

株式会社カタ技術
571-0042 大阪府門真市深田町9番8号
Tel 06-6908-9179
Fax、Email お問合せください
KATA GIJUTU Co.,Ltd.
9-8 Fukada-cyo Kadoma-city
Osaka Japan 571-0042
Tel 06-6908-9179

新着ニュースNew

ホームページ更新
Update WEB site

コンテンツを追加しました。

ワイヤーカット加工のページにFAQを追加しました。

また、今まではエクセルで計算していた、平歯車作図に要する要目の自動計算ツールを公開しました。

Added content.

FAQ has been added to the wire cut EDM page.

In addition, we have released on our website an automatic calculation tool for the important points needed when drawing spur gears, which were previously calculated using Excel.

2024年2月

記念
Memorial

Sankei Shimbun dated January 3, 2024 (Kitakawachi edition) Kadoma City's 60th anniversary and the same page KATA GIJUTU Co.,Ltd.'s 50th anniversary in the same newspaper.

2024年1月

型彫放電
EDM

Medical equipment 1.5mm wide hexagonal hole EDM Accuracy of ±0.02 is required.

2023年12月

型彫放電
EDM

3軸NC放電加工機を導入

アイトロニクス製放電加工機Ax1601を導入しました。フルデジタル電源制御搭載で、従来熟練技術者が行っていた加工条件の選定が不要になりました。小型ながら従来の放電加工機並みの機能を持ち合わせており、仕上がりも同等以上に加工できます。

3-axis NC electrical discharge machine introduced.

The Ax1601 EDM machine from Aitronix has been introduced. Equipped with full digital power control, it is no longer necessary for skilled technicians to select the machining conditions, which were previously done by skilled technicians. Despite its small size, the machine has functions comparable to conventional EDMs, and the finish can be machined to an equal or better standard.

2023年10月

地域活動
Regional activity

ふるさと門真まつりに「門真市ものづくり企業ネットワーク」わたがし屋台として参加しました。サポートセンタさんが記事にしてくださっていますので紹介します。

2023年8月

地域活動
Regional activity
カタノティーンズハローワーク

カタノプロフェショナル

2022年11月にも「カタノプロフェッショナル」記事で紹介していただきましたが、交野タイムズ様が個別のページも作成してくださいました。ありがとうございます。

Katano Professional

It was introduced in the "Katano Professional" article in November 2022, but the Katano Times also created an individual page. thank you.

2023年5月

型彫放電
EDM

A little rare. I did engraving electric discharge machining of characters.We asked the customer to produce the character electrodes, and the processing was successfully completed.I was able to deliver to another customer.Although it depends on the manufacturing conditions of the electrode, it is also possible to perform electric discharge machining of letters and shapes if there is data. We look forward to serving you.

2023年3月

社内行事
Event
忘年会2022

2022年忘年会

少し早めではございますが今年も頑張ってくれた社員への感謝をこめてささやかではございますが例年とおり心根さんで忘年会を開催しました。

Bonenkai2022

Although it was a little early, we held a Bonenkai at cocorone as usual, albeit modestly, to thank our employees for their hard work this year.

2022年11月

地域活動
Regional activity
カタプロ

カタノプロフェショナル

交野市に市内のプロフェッショナルな方々とそのお仕事を中高生に知ってもらおう!と活動している「カタノプロフェッショナル」というチームがあります。この度代表の片山が交野市在住という事で、記事を掲載頂き交野タイムズ様のホームページにてご紹介いただきました。子供たちが自身の将来を考える一助となればと思います。

Katano Professional

Let middle and high school students know about the professionals in Katano city and their jobs! There is a team called "Katano Professional" that is working with. This time, the president Katayama lives in Katano City, and was introduced on the homepage of "Katano Times". We hope it helps children think about their future.

2022年11月

社内環境
Office environment
空気清浄機

空気清浄機を設置

空気清浄機を導入しました。閉型のレーザ加工機で、集塵機をつないでいますが、目に見えない粉塵が舞っているのは否めませんでした。作業環境の改善に役立ってくれると思います。

Install an air purifier

Installed an air purifier. It's a closed laser processing machine, and it's connected to a dust collector, but I couldn't deny that there was invisible dust flying around. I hope it will help you improve your working environment.

2022年7月

コロナに負けるな!
Don't lose to the coronavirus

新型コロナ感染症弊社の取り組み

 この度、弊社では国内外での新型コロナウイルス感染症(COVID-19)拡大の防止のため、社員の検温を毎日、朝夕実施するためにサーマルカメラを導入しました。
マスク着用の徹底、手洗い、換気、人との間を一定の距離を計る事も引き続き対策し、新型コロナウイルス感染症の拡大防止に努めてまいります。

2021年10月

コロナに負けるな!
Don't lose to the coronavirus

新型コロナ感染症拡大予防についてのお願い

 平素より格別のお引き立てを賜り、厚く御礼申し上げます。
弊社では国内外での新型コロナウイルス感染症(COVID-19)拡大の防止のため、厚生労働省からのガイドラインに基づき、お取引先客様と社員とその家族の安全を考慮し以下の取り組みを行います。
当面の間、皆様にはお手数をおかけいたしますがご理解ご協力をお願いします。

- 記 -

1. マスク着用の徹底、手洗い、換気、人との間を一定の距離を計る。

2. 以下の項目に1つでも当てはまる方の来社はご遠慮ください。

 ・風邪の症状や37.5度以上の発熱がある方

 ・強いだるさ(倦怠感)や息苦しさ(呼吸困難)がある方

 ・咳やくしゃみが頻繁に出る方

 ・過去2週間以内に流行地域への訪問履歴がある方

3. 不要不急の来社はご遠慮ください。

4. 飛び込み営業もご遠慮ください。

5. ご来社いただく際には手指の消毒、マスク着用をお願いします。

6. 用件は必要最小限にとどめ、お打ち合わせも短時間でお済ませくださいます様よろしくお願いします。

以上

宅配の発送について

新型コロナ感染症の影響により、宅配での出荷が前日の予約制となりましたので通常より1日遅れます。予めご了承ください。

2021年1月

求人
Job Information

仲間を募集しています

2023年春高校卒業予定の私たちと一緒に働いてくれる仲間を募集しています。

2022年7月

コロナに負けるな!
Don't lose to the coronavirus

大阪府新型コロナ警戒信号

 弊社では、新型コロナウイルス感染症の感染拡大に伴う自粛要請・解除の基準となる大阪府独自の基本的な考え方「大阪モデル」に基づく警戒基準の到達レベルに関して、赤・黄・緑の3色でライトアップを実施し、地域の皆様へ周知してまいります。
 また、近隣住民の皆様に迷惑にならないよう、点灯は21時までと致します。

Osaka new coronavirus warning signal

At our company, three levels of red, yellow and green are used for the achievement level of the warning standard based on the Osaka prefecture's original basic idea "Osaka model" which is the standard for refraining from self-restraint due to the spread of new coronavirus infection We will carry out a light-up to inform everyone in the area. In addition, the lights will be lit up until 21:00 so as not to bother neighboring residents.

2020年5月

ワイヤーカット
WEDM

大型中精度ワイヤーカット入替

三菱製ワイヤーカット加工機FA20S Advance(2009年製)を中古導入しました。今まで頑張ってくれていたFX20Kと入れ替えになります。

Replacement of large medium-precision wire cut

Mitsubishi FA20S Advance (made in 2009) wire cutting machine was used.It will be replaced with FX20K, which has been working hard until now.

2020年2月

CAD
BricsCAD

BricsCADを導入

Brics社製BricsCAD ProV20、図研アルファテック株式会社製BJ-MechaTool Pro 2020を導入しました。DWG互換の2D/3D CADです。

BricsCAD introduced

BricsCAD ProV20 made by Bricsys nv and BJ-MechaTool Pro 2020 made by Zuken Alfatech Inc., were introduced.2D / 3D CAD compatible with DWG.

2019年11月

レーザ
Laser Cut
Bodori5

ファイバーレーザを導入

Bodor製ファイバーレーザ加工機i5を導入しました。米IPG社のレーザ発信機1kwが搭載されています。

Introduced fiber laser

Introduced Bodor fiber laser processing machine i5. It is equipped with a 1kw laser transmitter from IPG, USA.

2019年1月

測定器
Measurement
IM-7000

画像寸法測定器を導入

キーエンス製画像寸法測定器IM-7000を導入しました。測定顕微鏡の様な測定や輪郭の点群テータがDXF出力できます。

Introduced image size measuring device

Introduced IM-7000 image dimension measuring instrument manufactured by KEYENCE. DXF output of point cloud data of contours and measurements like a measuring microscope is possible.

2017年6月

測定器
Measurement
VR3000

ワンショット3D形状測定器を導入

キーエンス製ワンショット3D形状測定器VR-3000を導入しました。微細形状の3次元測定や表面粗さ測定ができます。

Introduced one-shot 3D shape measuring instrument

We introduced Keyence One-shot 3D shape measuring instrument VR-3000. 3D measurement of fine shape and surface roughness measurement are possible.

2017年6月

測定器
Measurement
XM1000

ハンディプローブ三次元測定器を導入

キーエンス製ハンディプローブ三次元測定器XM-1000を導入しました。ノギスやマイクロメータで測定不可な穴ピッチや面間距離が測定できます。

Introduced a handy probe 3D measuring instrument

Keyence Handy Probe CMM XM-1000 is introduced. We can measure hole pitch and face-to-face distance that cannot be measured with a caliper or micrometer.

2017年6月

社内環境
Office environment
ダクト

廃熱ダクトを設置

全てのワイヤー加工機から放出される排気熱を効率よく廃熱出来るよう廃熱ダクトを設置。夏場の作業環境が大幅に改善しました。

Install waste heat duct

A waste heat duct is installed to efficiently exhaust the exhaust heat emitted from all WEDM machines. The working environment in the summer has improved significantly.

2017年6月

社内環境
Office environment
エアコン

エアコン入れ替えと廃熱ダクトを設置

古くて消費電力の大きなエアコンを最新式に交換。同時に排気熱を効率よく排出出来るよう廃熱ダクトを設置。夏場の作業環境が大幅に改善しました。

Air conditioner replacement and waste heat duct installed

Replaced old air conditioners with large power consumption with the latest models. At the same time, a waste heat duct is installed to efficiently discharge exhaust heat. The working environment in the summer has improved significantly.

2017年6月

型彫放電
EDM

石定盤放電加工を導入

三菱製放電加工機EA8PVAdvanceを導入しました。System3RMacroチャックに対応して面粗度2マイクロメートルの加工ができます。

Introduction of stone surface plate electric discharge machining

Introduced the electric discharge machine EA8PVAdvance made by Mitsubishi. Corresponding to System3R Macro chuck, surface roughness of 2 micrometers can be processed.

2014年12月

ワイヤーカット
WEDM

高性能ワイヤーカット導入

三菱製ワイヤーカット加工機MV2400R Advance Plusを導入しました。オプションの超微細仕上加工用電源(Digital-FS電源)を搭載し、仕上げ面粗さ1マイクロメートル謳っています。

Introduction of high-performance wire cut

We introduced MV2400R Advance Plus, a Mitsubishi wire cut machine. Equipped with an optional ultra-fine finishing power supply (Digital-FS power supply), the finished surface roughness is 1 micrometer.

2013年12月

受賞・認証
Award・Certification Badges

守口門真ものづくり元気企業に認定

守口門真商工会議所より守口門真ものづくり元気企業に認定されました。

Certified as "Moriguchi Kadoma Genki Manufacturing Enterprise"

Moriguchi Kadoma Chamber of Commerce has certified our company as "Moriguchi Kadoma Monozukuri Energetic Company".

2013年

受賞・認証
Award・Certification Badges

大阪ものづくり優良企業賞に認定

優れた大阪のものづくり中小企業に与えられる大阪ものづくり優良企業賞(匠)に認定されました。

2013受賞一覧

Accredited to the Osaka Excellent Manufacturing Award

It has been recognized as the Osaka Monozukuri Excellent Company Award (Takumi), which is given to excellent Osaka manufacturing SMEs.

2013 Award List

2013年

受賞・認証
Award・Certification Badges

カドマイスターに認定

門真市が市内の優れた技術を持つものづくり企業に認定するカドマイスターに認定されました。新聞記事

2012年4月
